FoxESS F5000 - Dimensions

12
Warning!
Only authorized personnel are allowed to set the connection.
402mm
476.5mm
148mm
Object
A
B
C
D
E
F
G
H
I
Description
PV 1
PV 2
DC Switch (optional)
Waterproof Lock Valve
COM
USB
WiFi
AC Connector
Ground screw
3.3 Dimensions
Dimensions
E3000, E3600, E4600, E5000, E6000 F4600, F5000, F6000
