OBD II menu lets you access all OBD service modes. According to ISO 9141-2, ISO 14230-4, and
SAE J1850 standards, the OBD application is divided into several sub programs, called ‘Service
$xx’. Below is a list of OBD diagnostic services:
● Service $01 - request current powertrain diagnostic data
●
Service $02 - request powertrain freeze frame data
● Service $03 - request emission-related diagnostic trouble codes
● Service $04 - clear/reset emission-related diagnostic information
●
Service $05 - request oxygen sensor monitoring test results
● Service $06 - request on-board monitoring test results for specific monitored systems
●
Service $07 - request emission-related diagnostic trouble codes detected during current
or last completed driving cycle
● Service $08 - request control of on-board system, test or component
●
Service $09 - request Vehicle Information
When OBD II application is selected from Home screen, the scanner starts to detect the
communication protocol automatically. Once the connection has established, a menu that lists all of
the tests available on the identified vehicle displays. Menu options typically include:
● System Status
● Read Codes
●
Freeze Frame Data
● Clear Codes
● Live Data
●
I/M Readiness
● O2 Sensor Test
● On-board Monitor Test
●
Component Test
● Vehicle Information
● Modules Present
●
Code Lookup
NOTE
Not all function options listed above are applicable to all vehicles. Available options may vary by the
year, model, and make of the test vehicle. A “Not supported the mode!” message displays if the
option is not applicable to the vehicle under test.
5 TPMS Operations
This section illustrates how to use the TPMS Service Tool including how to activate & decode TPM
sensor data, how to do TPMS diagnosis and how to program OEM sensors etc.
To test the TPMS:
1. Choose Settings--Area from the Main Menu and select the area you work.
2. Highlight TPMS from the Main Menu and press the YES key to start.
