Remote Controller & Receiver Indicators
Remote Controller Indicators
Indicator
Prompt tone
Status
Solid Red
D-long tone
Boot Successfully
Red goes out
D-long tone
Shutdown Successfully
Flashing Red
D-D-D...
Low Battery Alarm
Receiver Indicators
Indicators
Status
L1
Flashing Blue
The receiver and remote controller are
connected successfully
L2
Solid Blue
The receiver is currently in configuration
mode and has no power output
RXD
Flashing Yellow
The receiver is receiving data
TXD
Flashing Yellow
The receiver is receiving data
S 1 、 S 2 、 S 3
Flashing Red
High signal quality
S 2
、
S 3
Flashing Red
Medium signal quality
S3
Flashing Red
Low signal quality
