FPV Model T20 - Receiver Pairing and Linking Process

10
Receiver pairing and configuration
Figure 1-4
1. As shown in figure 1-4，Before the receiver is powered on, long press
the SET button with a pin until the L2 indicator lights up solid blue,
and then release.
2. As shown in figure 1-5，connect the receiver and remote controller using
the equipped configuration cable.
Figure 1-5
