40
6 TRANSMITTING MIDI
SETTING UP THE MIDI PAYLOAD FOR A CONTROL SWITCH:
On the Axe-Fx III, open the SETUP | FC Controllers menu and page to the “ tab.
Use NAV buttons and the VALUE wheel to get around the page.
Select the desired control switch at the top of the menu. (CS1, CS2, etc.)
Make sure ENABLED is set to “YES” if you want the switch to send MIDI.
NAV through the table and create your desired MIDI Payload of up to
four commands, with different values for ON and OFF
For each command, selecting whether you want a Program Change (PC) or Control Change (CC) message.
Set the MIDI Channel for that command as desired from 1–16.
If you chose a CC Command, set the CC Number.
Set the desired Values for when the switch is ON and when it is OFF.
You can select values from 0–127, or “--” which means “send nothing.”
There is no need to save CS MIDI settings. They take effect immediately.
Remember, Control Switches can be switched manually using a footswitch, or automatically by Scenes.
See “Additional Control Switch Features” on p. 37.
