Table 1 Programming of Values
Programme
Mode No.
Description Pre-programmed
standard Value
Programme Range
-18- 5
th
harmonic
threshold in %
5 From 1 to 20 % in 0.1 % steps or
0.5 % steps at high speed.*)
-19- 7
th
harmonic
threshold in %
4 From 1 to 20 % in 0.1 % steps or
0.5 % steps at high speed.*)
-20- 11
th
harmonic
threshold in %
3 From 1 to 20 % in 0.1 % steps or
0.5 % steps at high speed.*)
-21- 13
th
harmonic
threshold in %
2.1 From 1 to 20 % in 0.1 % steps or
0.5 % steps at high speed.*)
-22- Harmonic
over-current
1.3 From 1.05 to 3.0 times the nominal
value in 0.05 steps or 0.1
increments at high speed
-23- Power factor
alarm tripping
signal
ON ON or OFF
By setting “OFF“ a power factor
alarm can be suppressed.
-24- Total kvar dis-
play
Will only be
displayed when in
operation
By pressing “set“ button the total
power in kvar will be displayed.
*) by pressing the buttons "+" or "-" for some time, the high speed mode will be activated.
