1T 310'177 Operating Manual Ecolino Erstellt: 01.05.2002 Rev.: C SL: 20'987 BJC
page 22
5. Briefly press the Clean key (Figure 5). clean
locked selection
6. Raise the tea and steam outflow and press the marked
area of the door (Figure 6) (The door must be opened
within 7 seconds, otherwise the coffee machine switches
back to the operating mode).
7. Completely open the door (Figure 7).
clean
open door
Figure 5 Figure 6 Figure 7
Figure 8 Figure 9 Figure 10 Figure 11
8. Pull out brewing piston and brewing table using a damp cloth (Figure 8).
9. Remove the grounds container by raising the tea and steam tube and empty. Then thoroughly
wash out the grounds container and dry with a cloth (Figure 9).
10. Remove remaining dirt using a cloth (Figure 10).
11. Insert the grounds container by raising the tea and steam tube (Figure 11).
