1T 310'177 Operating Manual Ecolino Erstellt: 01.05.2002 Rev.: C SL: 20'987 BJC
page 23
Figure12 Figure13 Figure14
12. Close the door (Figure 12). clean
locked selection
13. After the door has been closed, the display shows the
following after approx. 2 seconds: clean
cleaning tablet
14. Drop in tablet through filling funnel (Figure 13).
15. Press the Clean key (Figure 14). clean
locked selection
16. The automatic cleaning is started and takes from about 1 min to 6 min, depending on the
number of programmed cleaning cycles.
17. After the end of the 1st phase (points 1-16), the
following appears on the display: clean
please rinse
18. Now remove the milk container and wash it out (Figure 15).
19. Pour 1 litre of cold water into it (Figure 16).
20. Place the container back in the refrigerator, place the milk tube in the container and close the
door (Figure 17).
Figure15 Figure16 Figure17
