Freeform F2000 - Component Identification and Quantity

22
PARTS LIST
PART
NO. Description
Qty
PART
NO. Description
Qty
1 Main Frame
1
70
Right handle bar
1
2 Incline Bracket
1
71
Handle bar decoration
strip
2
3 Console Bracket
1
72
Wheel bushing
4
4 Left upright tube
1
73
AC single wire
Brown
2
5 Right upright tube
1
74
AC single wire
Blue
1
6 Front roller
1
75
Magnetic ring
1
7 Rear roller
1
76
Magnetic core
1
8 Motor belt
1
77
T shape Allen Wrench
6mm
1
9 Running desk
1
78
Open Wrench
19mm
1
10 Running belt
1
79
8# Allen Wrench
8mm
1
11 Motor top cover
1
80
5# Allen Wrench
5mm
1
12 Motor front cover
1
81
Phillips screwdriver
1
13 Left motor side cover
1
82
Big washer
2
14 Right motor side cover
1
83
Square oil bottle
1
15 Left upright tube cover
1
84
Oil driving system top
cover
1
16 Right motor trim cover
1
85
Oil driving system
bottom cover
1
17 Left side rail
1
86
Oil bottle fix plate
1
18 Right side rail
1
87
Oil control protect cover
1
19 Top side rail
2
88
Oil pipe 1
1
20 Left back end cover
1
89
Oil pipe 2
1
21 Right back end cover
1
90
Oil pipe 3
2
22 Rear top cover
2
91
Oil pipe 4
1
23 Side rail anti-slip pad
2
92
Glass tube fix button
3
24 Cushion
4
93
Speed sensor
1
25 Pipe cushion
6
94
Bolt
M5*10
22
26
Spring Ⅰ
6
95
Screw
ST3.5*10
19
27 Versatile Foot pad
2
96
Screw ST4.2*12
61
28 Side rail fix plate
6
97
Screw ST2.9*8
33
29 Brush
1
98
Nut
M8
17
30 Power line
1
99
Nut
M10
7
31 Square switch
1
100
Nut
M16
4
32 Power socket
1
101
Bolt
M16*50
4
33 Overload protector
1
102
Bolt
M10*45
4
34 Pressure plate frame
1
103
Bolt
M8*100
6
35 Ball bearing
2
104
Bolt
M10*70
1
36 Incline tube
2
105
Bolt
M10*45
1
37 Tension bolt
1
106
Bolt
M10*20
18
38 Tension spring
1
107
Bolt M8*35
4
39 AC motor
1
108
Bolt M8*16
1
40 Incline motor
1
109
Bolt M8*65
1
41 Inverter
1
110
Bolt M8*80
2
42 Error code board
1
111
Bolt M10*70
1
