Warning: Now here we suggest that you should consult with your physician or health professional
before starting your workout, especially for the age up to 35 old or once-health problem people. We
take no responsible for any troubles or hurts if you don’t following our specification. Treadmill will be
carefully assembled and covered the motor shield, then connect to the power.
ASSEMBLY INSTRUCTIONS
When you open the carton, you will find the below spare parts:
Parts List:
NO. DES. Specification Nos
.
NO. DES. Specification Nos.
1
Main Frame
1 100
Screw
ST4.2*12 2
106
Flat washer
8 8 A
Console
1
82
Bolt
M8*15 8 85
Bolt
M8*32 2
3
Wrench w/screw driver
S=13
、
14
、
15
1 80
Nut
M8 2
2
5#
Allen Wrench
5mm
1
49
Left upright tube cover
1
66
Handrail bottom cover
2 50
Right upright tube cover
1
Assembly tools:
5#Allen wrench 5mm 1pcs
、
Wrench with screw driver S=13
、
14
、
15 1pcs
