Freewing 80mm A-10 - Main Landing Gear Assembly

Main landing gear
Assembly
Step
1
Step
2
Step
3
A
C
B
D
E
E1
F
G
G1
H
I
I1
J
K
K1
L
M
N
O
Step
4
Step
5
A-
B -
C-
D-
E -
F -
G-
H-
Main gear axle
Main wheel (Ø85x26mm)
Grub Screw (M4x3)
L-Slant strut
Pin (Ø3.5X9.2mm)
Spring
C-Clip (Ø1.5mm) Main
Gear strut
I -
J -
K -
L -
M-
N -
O-
Accessories Description
15
A-10 Thunderbolt II
Item No.:FJ311
When assembling or disassembling the main landing gear, refer to the following diagram
Grub Screw (M4x3)
Main gear main rod
Grub Screw (M4x3)
Electronic retract
Main landing gear
Screw (PWA3x12 4pcs)
Main gear plastic cover
