PERFORMANCE EVAPORATOR AIR OPERATING ELECTRICAL R-22 COMP.
DATA* TEMP. °F. PRESSURES RATINGS REFRIG. OIL
Cooling DISCHARGE TEMP. SUCTION DISCHARGE AMPS LOCKED CHARGE IN CHARGE IN
AIR DROP °F ROTOR AMPS OZ. FLUID OZ.
ES12J33-1 58.0 22.0 77.5 266 5.5 26.3 25.0 11.8
ES12J33-3 5.7 26.3 26.0 11.8
ES15J33A-1 53.0 27.0 77.0 260 7.4 42.0 32.0 30.0
8.2
EM18J34A-2 55.0 25.0 73.0 262 8.2 42.0 47.0 30.0
EM18J34A-3 8.7 42.0 43.0 30.0
EL24J35A-1 55.0 25.0 73.5 280 12.0 61.0 53.0 32.0
EL24J35A-3 13.3 57.0 32.0
EL33J35-2 52.0 28.0 71.0 299 17.0 94.0 78.0 35.0
18.0
EK12J33A-1 57.0 23.0 79.0 293 5.8 26.3 26.5 11.8
EK12J33A-3 6.2 26.3 24.0 11.8
EK18J34A-2 55.0 25.0 73.0 262 8.2 42.0 46.0 30.0
EK18J34A-3 42.0 42.0 30.0
* Rating Conditions: 80°F Room Air Temperature and 50% Relative Humidity with
95°F Outside Air Temperature at 40% Relative Humidity.
PERFORMANCE DATA VOLTS BTUH CFM HEAT RISE
Heating HIGH SPEED
ES12J33-1 230 10700 1120 30.5
ES12J33-3 208 8900
ES15J33A-1 230 10700 1100 30.5
208 8900
EM18J34A-2 230 13000 1120 28.3
EM18J34A-1 208 10600
EL24J35A-1 230 17300 1100 28.6
EL24J35A-3 208 14300
EL33J35 230 17300 1110 22.8
208 14300
EK12J33A-1 230 10700 1080 30.5
EK12J33A-3 208 8900
EK18J34A-2 230 13000 1120 27.5
EK18J34A-3 208 10600
