Page 41
"YS" - "YM" - "YL" SERIES PARTS LIST
REF. PART NO. DESCRIPTION APPLICATION
YYYY
SSML
0112
9384
JJJJ
1333
0345
11AA
ELECTRICAL PARTS 2 1
1 615-628-07 Compressor, Tecumseh, 115 V, 60 Hz, 1 Ph, Model RK5480E ........ 1
1 615-628-05 Compressor, Tecumseh, 230/208 V, 60 Hz, 1 Ph, Model RK5513E . 1
1 617-187-01
Compressor, Bristol, 230/208 V, 60 Hz,1 Ph, Model H23B175ABCC ..................
1
1 611-935-47
Compressor, Tecumseh, 230/208 V, 60 Hz, 1 Ph, Model AWF5524EXN .................
1
* 603-645-94 Overload, Compressor - MRA4761-114 ........................................... 1
* 603-645-97 Overload, Compressor - MRA3795-114 ........................................... 1
2 610-714-93 Motor, Fan ...................................................................................... 1
2 610-714-94 Motor, Fan ...................................................................................... 1
] 2 610-714-96 Motor, Fan ...................................................................................... 1
2 610-714-85 Motor, Fan ...................................................................................... 1
3 605-000-54 Cord, Electric Supply - 15 Amp, 125 Volt ........................................ 1
3 605-000-49 Cord, Electric Supply - 20 Amp, 250 Volt ........................................ 1
3 605-000-48 Cord, Electric Supply - 30 Amp, 250 Volt ........................................ 1
3 605--000-55 Cord, Electric Supply - 30 Amp, 250 Volt ........................................ 1
4 606-072-04 Switch, System - 8 Position............................................................ 1 1 1 1
5 618-061-00 Switch, Rocker (Yes-No) ................................................................. 1 1 1 1
6 618-224-00 Thermostat (Cool & Heat) ............................................................... 1 1 1 1
* 613-503-13 Thermostat, Defrost ........................................................................ 1 1 1 1
7 610-803-38 Capacitor - 25/10 MFD, 370 V ......................................................... 1
7 610-803-37 Capacitor - 25/7.5 MFD, 370 V ........................................................ 1
7 610-803-36 Capacitor - 30/7.5 MFD, 370 V ........................................................ 1
7 610-803-56 Capacitor - 35/7.5 MFD, 370 V ........................................................ 1
* 618-208-00 Wire Harness, Fan Motor ................................................................ 1 1 1 1
* 618-213-00 Wire Harness, Compressor ............................................................. 1 1
* 618-213-02 Wire Harness, Compressor ............................................................. 1
* 618-211-00 Wire Harness, Compressor ............................................................. 1
* 618-624-08 Wire Harness, Solenoid .................................................................. 1 1 1 1
8 618-080-00 Resistor Block - 115 Volt ................................................................ 1
8 618-080-01 Resistor Block - 230 Volt ................................................................ 1 1 1
9 618-786-00 Heater Element - 3.3 KW ................................................................ 1
9 618-786-01 Heater Element - 4.0 KW ................................................................ 1
9 618-786-02 Heater Element - 5.2 KW ................................................................ 1
* 250-188-00 Solenoid - 120 Volt .......................................................................... 1
* 210-586-43 Solenoid - 230 Volt .......................................................................... 1 1 1
* 615-963-01 Fuse Link ....................................................................................... 1 1 1
* 618-279-00 Heater Limit .................................................................................... 1 1 1
REFRIGERATION SYSTEM COMPONENTS
10 618-501-00 Coil, Evaporator .............................................................................. 1 1
10 618-500-01 Coil, Evaporator .............................................................................. 1
* Not Shown
To Next Page
