Page 50
"ES" - "EM" SERIES PARTS LIST
REF. PART NO. DESCRIPTION APPLICATION
EE EEE
SS SMM
11111
22588
JJJJJ
33333
33344
31 AAA
CHASSIS PARTS 123
31 618-169-00 Insulation, Inner Wall ............................................................. 1 1 1
31 618-169-01 Insulation, Inner Wall ............................................................. 1 1
32 618-173-00 Blower Front .......................................................................... 1 1 1
32 618-174-00 Blower Front .......................................................................... 1 1
33 618-149-00 Scroll..................................................................................... 1 1 1
33 618-175-00 Scroll..................................................................................... 1 1
34 618-215-00 Door, Slide Assembly ............................................................ 1 1 1 1 1
35 618-090-05 Base Pan .............................................................................. 1 1
35 618-090-01 Base Pan .............................................................................. 1 1
35 618-090-09 Base Pan .............................................................................. 1
* 618-038-00 Drain Pan .............................................................................. 1 1 1 1 1
* 601-799-00 Bellows, Drain Valve .............................................................. 1 1 1 1 1
* 618-188-00 Grille Assembly (Rear) .......................................................... 1 1 1
* 618-188-01 Grille Assembly (Rear) .......................................................... 1 1
36 610-289-00 Grommet, Compressor .......................................................... 3 3 3 3 3
37 914-004-00 Bolt, Compressor Mounting ................................................... 3 3 3 3 3
38 618-102-00 Plenum Assembly ................................................................. 1 1 1 1 1
* 618-093-00 Knob, Fresh Air & Exhaust .................................................... 1 1 1 1 1
* 618-092-00 Lever, Fresh Air & Exhaust.................................................... 1 1 1 1 1
* 618-062-00 Connector, Louver ................................................................. 2 2 2 2 2
* 618-063-00 Louver ................................................................................... 20 20 20 20 20
* 618-063-01 Louver with Handle ................................................................ 2 2 2 2 2
39 618-257-00 Outer Shell (Carton with Sill Plate) ........................................ 1 1 1
39 618-257-01 Outer Shell (Carton with Sill Plate) ........................................ 1 1
40 618-084-01 Sill Plate ............................................................................... 1 1 1 1 1
* 618-196-00 Guide, Shell .......................................................................... 2 2 2 2 2
41 618-089-00 Grille, Intake.......................................................................... 1 1 1
41 618-111-00 Grille, Intake.......................................................................... 1 1
* 618-199-00 Latch, Intake Grille ................................................................ 2 2 2 2 2
* 617-173-01 Gasket, Chassis Seal ........................................................... 1 1 1 1 1
* WIKS Accessory Package (Optional) Window Mount ....................... 1 1 1
* WIKM Accessory Package (Optional) Window Mount ....................... 1 1
* 608-460-16 Bag Assembly (Hardware) ..................................................... 1 1 1 1 1
OPTIONAL ACCESSORIES
* 01900-235 Drain - Condensate Connection Kit, DC-2 .............................. x x x x x
* 610-089-03 Start Kit, Capacitor/Relay (Pow-R-Pak) ................................. x x x x x
* Not Shown
