Friedrich FPWC1 Service Manual

11 PB
SPECIFICATIONS
Product Specications Multi-Zone Wall-Mounted
PERFORMANCE RATINGS Multizone Wall-Mounted - Heat Pumps
7k 9k 12k 18k 24k
INDOOR MODEL FPHMW07A3A,
FPHMW07A3B
FPHFW09A3A,
FPHFW09A3B
FPHFW12A3A,
FPHFW12A3B
FPHFW18A3A,
FPHFW18A3B
FPHFW24A3A,
FPHFW24A3B
SPECIFICATIONS
CAPACITY
COOLING (RATED)
BTU 7,000 9,000 12,000 18,000 24,000
CAPACITY
HEATING (RATED)
BTU 8,500 9,500 13,000 19,000 24,200
MOISTURE
REMOVAL
Pts/h 2.5 2.5 3.2 4.2 5.3
AIRFLOW
(TURBO/HIGH/
MED/LOW)
CFM 424/382/323/247 424/382/323/247 424/382/323/247 618/565/482/382 735/665/559/441
SOUND RATING
(HIGH/MED/LOW)
dB-A 38/32/29 38/32/29 39/32/29 45/41/37 48/45/40
ELECTRICAL DATA
POWER SOURCE V, Ø,
Hz
208-230/60/1 208-230/60/1 208-230/60/1 208-230/60/1 208-230/60/1
POWER AND
COMMUNICATION
CABLES
TYPE 14/4 AWG
600V THHN
14/4 AWG
600V THHN
14/4 AWG
600V THHN
14/4 AWG
600V THHN
14/4 AWG
600V THHN
REFRIGERATION SYSTEM
CONNECTIONS Flare Flare Flare Flare Flare
LIQUID LINE O.D. in 1/4 1/4 1/4 1/4 3/8
SUCTION LINE
O.D.
in 3/8 3/8 3/8 1/2 5/8
DIMENSIONS & WEIGHT
W x H x D in 37 3/8"x 10 3/4"x
81/8"
33 7/8 x 11 3/16
x 8 1/2
33 7/8 x 11 3/16
x 8 1/2
48"x 12 5/8"x
91/4"
48"x 12 5/8"x
91/4"
NET WEIGHT lbs 18.7 18.7 18.7 32 32
SHIPPING
WEIGHT
lbs 24.3 24.3 24.3 37.5 37.5
