R-410A SEALED SYSTEM REPAIR
Replace 9k, 12k, and18k Cassette Type unit Compressor and Motor
Replacement of Fan Motor
Step
Illustration
Handli ng Instruction
1.
Loose
n the screws
holding condensate pan .
Use screwdriver to loosen
the screws holding the
drain pan in place.
pan
2.
Remove the condensate
Carefully remove
the condensate
pan.
3.
Loosen the bolt holding
the fan blade in place
Use a wrench or socket to
carefully remove the fan
blade bolt.
4. Remove the fan blade
The fan blade can now
be removed.
5.
Loos en the bolts holding
the motor in place
Use a wrench or socket
to carefully remove the
motor bolts.
