Friedrich FPWC1 Service Manual

13 PB
SPECIFICATIONS
Product Specications Multi-Zone Concealed Ducted
PERFORMANCE RATINGS Multizone - The Insider™ Concealed Ducted Heat Pumps
9k 12k 18k
INDOOR MODEL FPHFD09A3A FPHFD12A3A FPHFD18A3A
SPECIFICATIONS
CAPACITY COOLING (RATED) Btu 9,000 12,000 18,000
CAPACITY HEATING (RATED) Btu 10,000 12,500 19,000
MOISTURE REMOVAL Pts/h 1.9 3.2 3.2
Max Airow (@0.1 E.S.P.) CFM 294 353 529
SOUND RATING (MAX.-MIN.) dB-A 33/26 34/27 35/31
ELECTRICAL DATA
POWER SOURCE V, Ø, Hz 208-230, 1, 60 208-230, 1, 60 208-230, 1, 60
POWER AND COMMUNICATION
CABLE
TYPE 14/4 AWG
600V THHN
14/4 AWG
600V THHN
14/4 AWG
600V THHN
REFRIGERATION SYSTEM
CONNECTIONS Flare Flare Flare
LIQUID LINE O.D. in 1/4 1/4 1/4
SUCTION LINE O.D. in 3/8 3/8 1/2
DIMENSIONS & WEIGHT
W X H X D in 35 7/8 x 7 7/16 x 17 35 7/8 x 7 7/16 x 17 46 7/16 x 7 1/2 x 17 1/2
NET WEIGHT lbs 45.2 45.2 66.2
SHIPPING WEIGHT lbs 51.8 51.8 77.2
NOTE:
1. Test conditions
Cooling: Indoor: DB80°F(26.7)/ WB67°F(19.4) Outdoor: DB95°F(35)/ WB75°F(23.9)
Heating: Indoor: DB70°F(21.1)/ WB60°F(15.6) Outdoor: DB47°F(8.3)/ WB43°F(6.1)
2. The Sound Pressure Level is based on the following conditions:
Indoor unit
Duct:
Measure the noise value of the point 4.6ft(1.4m) below the unit and 3.3ft(1.0m) high from the ground.
3. The above data was measured in an anechoic chamber. Please take into consideration reected sound of your specic
application environment.
4. All specications are subjected to change by the manufacturer without prior notice.

Friedrich FPWC1 Specifications

General

Brand	Friedrich
Model	FPWC1
Category	Air Conditioner
Language	English
