COMPONENTS TESTING
Field Settings (Outdoor 24k and 36k)
Paramet er
Descriptions Dual Trio Quattro
P.0 Fault codes ● ● ●
P.1 ● ●Compressor actual frequency ●
P.2 ● ● ●Compressor driving frequency
P.4 ● ● ●Compressor target frequency
P.5 ● ● ●Compressor exhaust temperature
P.6 ● ● ●Outdoor suction Temperature
P.7 ● ● ●Outdoor ambient temperature
P.8 ● ●Outdoor coil temperature ●
P.9 ● ●Outdoor defrosting temperature ●
P.10 ● ●IPM module temperature ●
P.11 ● ● ●Outdoor capacity requirement
P.12 ● ●IPM fault codes ●
P.13 ● ● ●Outdoor DC Motor target speed
P.14 ● ●AC input current ●
P.15 ● ●AC input voltage ●
P.16 ●DC bus voltage ● ●
P.17 ● ●Compressor phase current ●
P.18 ● ●Frequency limit code ●
P.20 ● ● ●Target suction overheating
P.21 ● ● ●Target exhaust overheating
P.22 ● ● ●Actual suction overheating (heating)
P.23 ● ● ●Actual exhaust overheating (heating)
A.1 ● ●Unit A fault codes ●
A.2 ● ● ●Unit A valve actual opening
A.4 ● ● ●Unit A liquid pipe temperature
A.5 ● ● ●Unit A gas pipe temperature
A.6 ● ● ●Unit A coil temperature
A.7 ● ●Unit A ambient temperature ●
A.8 ● ●Unit A set temperature ●
A.9 ● ●Unit A capacity ●
A.10 ● ●Unit A set fan speed ●
A.11 ● ● ●
Unit A actual suction overheating
B.1 ● ●Unit B fault codes ●
B.2 ● ● ●Unit B valve actual opening
B.4 ● ● ●Unit B liquid pipe temperature
B.5 ● ● ●Unit B gas pipe temperature
B.6 ● ●Unit B coil temperature ●
B.7 ● ●Unit B ambient temperature ●
B.8 ● ●Unit B set temperature ●
B.9 ● ●Unit B capacity ●
B.10 ● ●Unit B set fan speed ●
B.11 ● ● ●
Unit B ac
tual suction overheating
C.1  ●Unit C fault codes ●
C.2  ● ●Unit C valve actual opening
C.4  ● ●Unit C liquid pipe temperature
C.5  ● ●Unit C gas pipe temperature
C.6  ●Unit C coil temperature ●
C.7  ● ●Unit C ambient temperature
C.8  ●Unit C set temperature ●
C.9  ●Unit C capacity ●
C.10  ●Unit C set fan speed ●
C.11  ● ●
Unit C ac tual suction overheating
D.1   Unit D fault codes ●
D.2   ●Unit D valve actual opening
D.4   ●Unit D liquid pipe temperature
D.5   ●Unit D gas pipe temperature
D.6   Unit D coil te
mperature ●
D.7   ●Unit D ambient temperature
