Filter Removal / Installation Instructions - Kuhl Q
1. Swing the door open, See Figure 410,and remove the lter by grasping the lter grips and pulling the bottom towards you. . See Figure 411.
2. Clean the front frame by removing the carbon lter (if installed) and washing the dirt from the lter. Use a mild soap solution if necessary. Allow lter to dry.
NOTE: The carbon lter is not a reusable lter, and needs to be replaced every three months for optimum efciency.
3. Install new carbon lter (optional) by aligning holes on carbon lter with tabs on mesh lter. (See Figure 412).
4. Install lter and close door. See Figures 409 and 410.
Figure 410
Figure 411
Filter
Filter grip
Filter Frame Tabs
Figure 412
