119 PB
Figure 902
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
1 69700315 Jumper MWM18Y3J 1
1a 69700292 Jumper MWM24Y3J 1
2 69700293 Indicato r Shield Gover MWM18Y3J, MWM24Y3J 1
3 69700294 Indicator Light Cover MWM18Y3J, MWM24Y3J 1
4 69700295 Display Board MWM18Y3J, MWM24Y3J 1
5 69700296 Eleclr ic Box MWM18Y3J, MWM24Y3J 1
6 69700130 Terminal Board MWM18Y3J, MWM24Y3J 1
7 69700297 Electric Box Shield Cover MWM18Y3J, MWM24Y3J 1
8 69700316 Main Board MWM18Y3J 1
8a 69700298 Main Board MWM24Y3J 1
9 69700317 Electric Box Assy MWM18Y3J 1
9a 69700299 Electric Box Assy MWM24Y3J 1
10 69700318 Electric Box Cover MWM18Y3J 1
10a 69700300 Electric Box Cover MWM24Y3J 1
11 69700301 Electric Box Cover Shield MWM18Y3J, MWM24Y3J 1
12 69700319 Electric Box Cover MWM18Y3J 1
12a 69700302 Electric Box Cover MWM24Y3J 1
16 69700320 Front Panel MWM18Y3J 1
16a 69700303 Front Panel MWM24Y3J 1
17 69700321 Front Case Assy MWM18Y3J 1
17a 69700304 Front Case Assy MWM24Y3J 1
18 69700322 Screw Cover MWM18Y3J 1
18a 69700138 Screw Cover MWM24Y3J 1
19 69700323 Fan Motor MWM18Y3J 1
19a 69700305 Fan Motor MWM24Y3J 1
20 69700324 Louver Guide MWM18Y3J 1
20a 69700306 Louver Guide MWM24Y3J 1
21 69700172 Axile Bush MWM18Y3J, MWM24Y3J 1
22 69700325 Evaporator Assy MWM18Y3J 1
22a 69700307 Evaporator Assy MWM24Y3J 1
23 69700118 Connecting pipe clamp MWM18Y3J 1
23a 69700308 Connecting pipe clamp MWM24Y3J 1
24 69700326 Cross Fl ow Fan MWM18Y3J 1
24a 69700169 Cross Fl ow Fan MWM24Y3J 1
25 69700327 Motor Press Plate MWM18Y3J 1
25a 69700185 Motor Press Plate MWM24Y3J 1
26 69700328 Stepping Motor MWM18Y3J 1
PARTS CATALOG
Indoor Unit MWM18Y3J, MWM24Y3J
