120 PB

Figure 902

ITEM PART

NUMBER

PART DESCRIPTION USED ON MODEL QTY

26a 69700206 Steppting Motor MWM24Y3J 1

27 69700 124 Crank MWM18Y3J, MWM24Y3J 1

28 69700329 Helicoid Tongue MWM18Y3J, MWM24Y3J 1

29 69700330 Air Louver MWM18Y3J 2

29a 69700310 Air Louver MWM24Y3J 2

30 69700331 Drainage Hose MWM18Y3J 1

30a 69700311 Drainage Hose MWM24Y3J 1

31 69700332 Rear Case Assy MWM18Y3J 1

31a 69700312 Rear Case Assy MWM24Y3J

32 69700333 Wall Mountiing Frame MWM18Y3J 1

32a 69700153 Wall Mountiing Frame MWM24Y3J 1

33 69700115 Rubber Plug {Water Tra y) MWM18Y3J, MWM24Y3J 1

34 69700111 Left Axile Bush MWM18Y3J, MWM24Y3J 1

35 69700112 Ring of Bearing MWM18Y3J 1

35a 69700187 Ring of Bearing MWM24Y3J 1

36 69700313 Remote Control MWM18Y3J, MWM24Y3J 1

37 69700314 O-Gasket Sub-assy of Bearing MWM18Y3J, MWM24Y3J 1

38 69700334 Evaporator Support MWM18Y3J 1

38a 69700182 Evaporator Support MWM24Y3J 1

39 69700335 Filter Sub-Assy MWM18Y3J 2

39a 69700173 Filter Sub-Assy MWM24Y3J 2

-ITEMS ARE NON- ILLUSTRATED

*ITEMS ARE NON-STOCKED, WILL NORMALLY REQUIRE 2-3 WEEKS LEAD TIME

PARTS CATALOG

Indoor Unit MWM18Y3J, MWM24Y3J
