115
11.8.2 Igniter Accessibility
Step: 1
Loosen the screws of the Heat shield (1, 2 and 3) which is
fitted with the Burner Tube.
Step: 2
Remove the wire clip (1) and loosen the screw (2) from the
Adapter plate to separate the igniter.
NOTE
The Igniter material is soft and brittle. Handle it with care.
11.8.3 Gas Valve Assembly Accessibility
Loosen the Gas Valve Bracket screws (3) to separate the Gas Valve Assembly.
