Frigidaire FFLE4033QW - Program Selector Accessibility; Temperature Selector Accessibility

139
14.1.2 Program Selector
Accessibility
Step: 1
Remove the Program Selector knob from the console as
shown in Fig.1.
Step: 2
Detach the connector from the Cycle Selector Switch (See
Fig. 2), and then unfasten the snaps (2) to remove the switch
from the console (See Fig. 3).
14.1.3 Temperature Selector
Accessibility
Step: 1
Remove the Temperature Selector knob from the console
as shown in Fig.1.
Step: 2
Detach the connector from the Temperature Selector
Switch (See Fig. 2) and unfasten the snaps (2) to remove
the switch from the console (See Fig. 3).
