9. ELECTRICAL COMPONENTS - FFLE3911QW and
FFLG4033QW
9.1 Electrical Component Resistance and Specification Table
FFLE3911QW and FFLG4033QW - DRYER
S.No Component Specification
1 Inlet / Outlet Control
Thermistor
Resistance = 50KΩ ± 5% at (25ºC)
Resistance = 12.4KΩ ± 2% at (60ºC)
Operating Temp.= - 40˚C to +105˚C
2 Door Switch Contact Rating to Meet = 10A,1/3HP,125/250 VAC,
Operating force = 500gf.
3 Heating Element (For
Electrical Dryer Model
only)
PERFORMANCE SPECIFICATIONS
Voltage - cycles 115V- 60Hz ,4.8 AMPS
Breakdown torque, ft - oz 24.4 nom
Locked rotor current, amps 47 max
Full load torque, ft - oz 12.2 nom
Full load current, amps 4.6 nom
Full load, watts 340 nom
Full load, rpm 1685 nom
Horse power 1/4 hp output
Locked rotor trip time 3-6 sec
INSULATION – CLASS F
4
Heating Element (For
Electrical Dryer Model
only)
Wattage: 4500W ± 3%, Voltage 240V.
Resistance across the Terminals: 11Ω ± 10%.
5 Inlet Thermal Limiter
U.L. and C.S.A . Rated:
125/250 VAC 25 A Resistive,
125 VAC, 20 F.L.A.,60 L.R.A.Inductive,
240 VAC, 10 F.L.A., 60 L.R.A. Inductive.
Opening Temp: 275º ±10.8ºF,Closing Temp: -31ºF.
