9.1 Electrical Component Resistance and Specification Table
FFLE3911QW and FFLG4033QW - DRYER
S.No Component Specification
6 Outlet Thermal Limiter
U.L. Rated : 240V, 10A F.L.A and 60A L.R.A at 350ºF,
C.S.A . Rated: 120V 15A Resistive.
Opening Temp: 222ºF ± 8ºF,
Closing Temp: -31ºF.
7
Igniter (For Gas Dryer
Model only)
Steady State Current to be 2.1 to 3.4 AMPS AT 80 ± 1 VAC and 75º ±
10ºF, Igniter must not exceed 2800 ºF in 10 seconds at 132 ±1 VAC &
75ºF ± 10ºF Ambient.
