FFLE3911QW and FFLG4033QW – WASHER
S.No Component Specification
1 Lid Lock
Internal contacts : 120 / 240 VAC, 50 / 60 Hz; Electrical Life:
15000 cycles @ 3A; External Micro switch: 16A , 250V,
Power : 1 HP @ 125 VAC, 2 HP @ 250 VAC,105 Ω ± 10%
(Resistance @ 25 ˚C).
2 Drain Pump
12 to 17 Ω (Resistance at 25 ºC) 120 V AC, 60 Hz, 1.4 A, 80W
Discharge Rate (Under Variable Head): At 3 FT height from floor:
12 GPM MIN. At 8 FT height from floor: 7 GPM MIN.
3
Dispenser Solenoid
valve (3 coil – For
Model FFLG4033QW)
1375 Ω ± 10% (Resistance at 25 ºC); 120 V, 60 Hz, 6 / 5 Watts.
4
Dispenser Solenoid
valve (2 coil – For
Model FFLE3911QW)
1375 Ω ± 10% (Resistance at 25 ºC); 120 V, 60 Hz, 6 / 5 Watts.
5
3 Phase Synchronous
Motor
M1---M2 - 6 to 8 Ω
M2---M3 - 6 to 8 Ω
M1---M3 - 6 to 8 Ω
150 V / 180 V, 54.2 / 83.3 Hz
2.76 / 1.96 A, 385 / 420 W
650 / 1000 RPM
6 Motor Brake Clutch 2900 to 3100 Ω (Resistance at 25 ºC ); AC 120 V, 60 HZ, 2mA
7 Pressure Sensor
Nominal Voltage : 5 ± 0.25 VDC; maximum current: <5
mA; Maximum Operating Temperature: 85 ºC (65 ºC for UL
application); pressure working range 0 - 600 mm of H2O
