5.1.2 Motor/Blower/Belt
POS. NO DESCRIPTION
1 Seal, air duct
3 Shield, air duct
4 Fastener, push-in
6 Duct, air
7 Seal, housing, to air duct
9 Clamp
10 Housing, blower, front w/seal
10A Housing, blower, rear
12 Blower Wheel
15# Thermistor, control
16 Screw, pan head, 8-18AB x 0.375
18 Cradle, motor w/idler
19 Pan ,Upper L/C, dryer, formed
22 Spring, idler
23 Idler Arm Assy, with pulley
23*# Terminal Block, main
25 Belt, dryer, LC
26 Block, support
27 Clamp, motor mtg.
28# Motor, dryer drive ,with pulley
33 Shield-access
38 Elbow, 90 Deg 4" Fixed
39 Screw ,#8 pan head, 10-10B x 0.500, cr/sq drive
41 Bracket, support, side
42 Bracket, marriage, dryer
44 Bracket, L mounting, cabinet rear, external
48 Pan, bottom LC dryer
50 Cover, support, LCD
51 Bushing, snap-in
80 Screw, pan head, 8-18B x 0.31
# Functional parts
* Non-Illustrated parts
