5.1.3 Control Panel
POS. NO DESCRIPTION
1 # Control Board, main, with housing
3 # Wiring Harness, dryer, LC upper
4 Knob,switch
6# Harness, UI, washer, LC
8# PC Board, communication, with housing
15# Switch, PTS cycle select, 8 position
18 Console, decorated, white
21 Knob, Cycle Selector
22 Screw ,#8 pan head, 10-10B x 0.500, cr/sq drive
23 # Wiring Harness, main, LC
23*# Terminal Block, main
29 # Wiring Harness, LC Dryer, electrical
32 Cable Tie, 5.60 inch, plastic
39 # Switch, Option 3 pos
80 Screw, Phillips, 6-19 x 0.650
# Functional parts
* Non-Illustrated parts
