5.2.2 Motor / Blower / Belt
POS. NO DESCRIPTION
1 Seal, air duct
4 Clip, end cap mtg, U-type
6 Duct, air
7 Seal, housing, to air duct
8 Screw, pan head, 6-18AB x 0.60
9 Clamp
10 Housing, blower, front, with seal
10A Housing, blower, rear
12 Blower Wheel
15 # Thermistor, control
16 Screw, pan head, 8-18AB x 0.375
18 Cradle, motor w/idler
19 Pan, Upper L/C, dryer, formed
22 Spring, idler
23 Idler Arm Assy, with pulley
25 Belt, poly V
26 Block, support
27 Clamp, motor mtg.
28 # Motor, dryer drive, with pulley
31 Power Cord, electric svce
33 Shield, access area, cover
34 Screw, hex washer head, 10-32 x 0.375, ground
38 Elbow, exhaust duct
39 Screw, #8 pan head, 10-10B x 0.500, cr/sq drive
41 Bracket, support, side
42 Bracket, marriage, dryer
44 Bracket, L mounting, cabinet rear, external
48 Pan, bottom LC dryer
50 Cover, support, LCD
51 Bushing, snap-in
61 Bracket, gas valve mtg
64 Pipe, gas
65 Cap, pipe
70 # Valve, gas
71 # Solenoid, secondary coil
72 # Solenoid, booster coil
73 # Oriļ¬ce,natural gas, size 44
74 # Igniter, Assy
