5.2.3 Control Panel
POS. NO DESCRIPTION
1 # Control Board, main, with housing
3 # Wiring Harness, dryer, LC upper
4 Knob, Switch
6 # Harness, upper LC, wash
8 # PC Board, communication, with housing
13 # Switch, on/off, white, round
15 # Switch, PTS cycle select, 9 pos
18 Console, decorated, control panel
21 Knob, Cycle Selector
22 Screw, #8 pan head, 10-10B x 0.500, cr/sq drive
23 # Wiring Harness, main
29 # Harness, main, LC-D-gas
32 Cable Tie, 5.60 inch, plastic
39 # Switch, rotary, 2 pos
40 # Switch, rotary, 5 pos
41 # Switch, rotary, 4 pos
80 Screw, Phillips, 6-19 x 0.650
# Functional parts
* Non-Illustrated parts
