33
5.3.4 Cabinet Assembly
POS. NO DESCRIPTION
1 Screw
2 Upper Bracket Assembly
3 Backsheet Panel
4 Side Panel, 2 PLCS
5 Screw,12 PLCS
6 Screw,15 PLCS
7 Structural Bracket (RH)
8 Base Assembly
9 Structural Bracket (LH)
10 Screw, 4 PLCS
#11 3 Coil water valve (Model FFLG4033QW)
#11A 2 Coil water valve (Model FFLE3911QW)
12 Low Frequency Analog Pressure Sensor
13 Top Panel and Lid Assembly
14 Lid Lock
15 Fastener
16 Screw
17 UIMC Assembly
18 Bracket,UIMC
19 Cover, UIMC
#20 Softener Dispenser Assembly (Model FFLG4033QW)
#20A Bleach Dispenser (Model FFLE3911QW)
# Functional parts
To Next Page
