87
Performance Specifications
Voltage - cycles 115V-60Hz ,4.8 AMPS
Breakdown torque, ft - oz 24.4 nom
Locked rotor current, amps 47 max
Full load torque, ft - oz 12.2 nom
Full load current, amps 4.6 nom
Full load, watts 340 nom
Full load, rpm 1685 nom
Horse power 1/4 hp output
Locked rotor trip time 3-6 sec
INSULATION - CLASS F
Specifications - FFLE3911QW and FFLG4033QW (Dryer)
Wiring Diagram - FFLE3911QW
Wiring Diagram - FFLG4033QW
