Page
18
Fridges & Freezers Boxes
SERIE MS
STAINLESS STEEL
Series
If you want to fasten the box using the frames, it is
necessary to drill into its walls some holes, as you
can see in the picture.
You can drill some holes only before mounting the
frames. Then you must consider also the material
they must be fasten to and the screws head.
On the box walls there are some holes to
fasten stainless steel profiles (picture 4), that
fit perfectly the cabinet in the chosen seat
(picture 4).
On the profiles there are some holes to fix
them on the box (the kit includes screws) .
Pay attention to the hinges and the handle
position since the profiles have their own join
seats (pictures 2 and 3).
How to fasten the box with the
frame kit
3. INSTALLATION
3.9 Fastening with frame kit
picture 1
picture 2
picture 3
picture 4
