Frigoboat MS SERIES - 2. Components Table; 2.1 Components Description (with hidden evaporator)

Page
3
2. COMPONENTS TABLE
Fridges & Freezers Boxes
SERIE MS
STAINLESS STEEL
Series
2.1 Components description (with hidden evaporator)
3.1
3.4
3.2
6.4
3.2
5.6
5.5
FRIDGE FREEZER
A = RAPID HOOK-UPS
B = THERMOSTAT
C = LIGHT
D = RECHAUFFAGE PORTE
(FILO CALOR)
E = CONDENSATION OUTLET
G = VOLTAGE WARNING LIGHT
B
C
C
B
G
A
E
A
D
G
