FRITZ!Box 7490 100
LISP: FRITZ!Box as a LISP Router
Properties of RLOC and EID
Components of a LISP System
RLOC specifies the location where the addressed network
(network segment or network device) is located
is assigned by the Internet service provider
is a public IP address
is contained in the external header of the LISP packet
can be an IPv4 address
can be an IPv6 address
EID
identifies a network (network segment or network de-
vice)
is assigned by the LISP provider
is contained in the internal header of the LISP packet
can be an IPv4 address
can be an IPv6 address
can be a public IP address
can be a private, non-public IP address
Mapping system The mapping system is responsible for allo-
cating the EIDs to the RLOCs.
ETR (Egress Tunnel
Router)
The ETR accepts IP packets whose destination
IP address contained in the external header is
the ETR’s own RLOC. ETR unpacks the LISP
packets.
ITR (Ingress Tunnel
Router)
The ITR accepts IP packets from members of
the local IP network (EID network) and packs
them into LISP packets. The external header of
the LISP packet contains the RLOC of the des-
tination network (remote EID network) as the
destination address.
