Fromm FS360 Series - Film Feed and Roller Maintenance; Film Specifications and Roller Cleaning

FROMM SERVICE MANUAL FS360_EN01 Version00.doc
For further updates, see our website www.fromm-stretch.com and Login!
It is forbidden to duplicate this manual or parts thereof or any other form without the author’s authorisation © 2018
30
FILM FEED
Film - LLDPE material Max. 35 μ / 0,000138”
- Roll internal diameter 76.2 mm / 3”
- Roll external diameter Max. 250 mm / 11.20”
- Film width Max. 500 mm / 19.69”
IMPORTANT: CLEANING THE RUBBER ROLLERS
The stretchable film releases deposits of silicone on the rubber rollers
(depending on the film used).
It is very important that the rubber rollers are cleaned periodically with alcohol,
in this way the normal adhesiveness between the roll and the film will be
restored.
Carriage with roll core brake
Fig.1
Fig.2
Carriage with one roll brake
Fig.1
Fig.2
Carriage with one motor pre-stretch fixed
Fig.1
Fig.2
