CONTROL PANEL
Key
Description
Moving the carriage in Manual Operation Mode.
Before of all choose manual wrapping
Selector with return to the centre, in Manual mode, keeping the selector in the left
position the carriage movement downwards is activated, while keeping the selector
in position on the right, the upward movement is activated: leaving the selector,
this returns to the centre, stopping any movement of the carriage.
Speed turntable.
Potentiometer for adjusting speed turntable.
(Adjustment from 6 to 12 rpm).
Speed carriage.
Potentiometer for adjusting speed carriage.
(Adjustment from 2 to 4 meter/minute).
Stretch film carriage (available only with carriage pre-stretch).
Potentiometer for adjusting stretch film carriage.
