8
5.3 Feeding the strap around the
package
The strapping is fed around the package as
illustrated.
Warning! The plastic strap which will be welded
must be free from oil, grease and other dirt.
Dirty plastic straps can't be welded correct!
5.4 Inserting the strap
Pull up the handle lever firmly with your right
hand.
Insert the two straps well aligned on each other
into the strap guide using your left hand.
Release the handle lever.
5.5 Tensioning the strap
Press down the switch rocker and then release it
again after the desired strap tension has been
reached.
The tensioning operation can be interrupted and
restarted at any time.
The tool must carry out a balance movement
while tensioning.
Therefore:
- Don’t hinder the tools movement in the
signed direction.
Disregard:
- The feed wheel slips on the strap without
tensioning it.
To Next Page
