* = Wearing Parts [ ] = Group ->[ ] = in Group
12
6 SPARE PARTS LIST 43.0324.02
43.0324.02 P320/12.7/0.65-1.05 P320.0001.02 01/10/98
Item-No. Pcs. Description Dimension Field
N1.1305 2 SCREW M4 X 8 D3
N1.1328 ->[P32.0114] 2 SCREW M3 X 10 C4
N1.1553 ->[P32.1250] 1 HEXAGON SCREW M4 X 8 C5
N1.1904 5 FLAT HEAD SCREW M5 X 20 E6+
N1.1909 2 FLAT HEAD SCREW M3 X 5 E3+
N1.1915 ->[P32.0114] 2 FLAT HEAD SCREW M4 X 8 D5
N1.1929 1 FLAT HEAD SCREW M5 X 50 D7
N1.1934 ->[P32.0114] 6 FLAT HEAD SCREW M4 X 50 A4+
N1.2112 ->[P32.0103] 3 COUNTERSUNK SCREW M4 X 10 C1
N1.2223 2 COUNTERSUNK SCREW M3 X 6 E4+
N1.6108 ->[P32.0114] 1 WASHER 12 X 16 X 2 C5
N1.6205 ->[P32.0114] 2 SPRING LOCK WASHER M4 D5
N1.6309 ->[P32.0114] 1 SPACER WASHER 10,05 X 16 X 0,5 B5
N1.6312 ->[P32.0114] 1 SPACER WASHER 8 X 14 X 1,2 C2
N1.6331 ->[P32.0114] 4 SPACER WASHER 6 X 12 X 0.5 B6+
N1.6503 6 SAFETY WASHER M5 E6+
N1.6504 2 SAFETY WASHER M4 D3
N1.6504 ->[P32.0114] 6 SAFETY WASHER M4 B3+
N1.6504 ->[P32.1250] 1 SAFETY WASHER M4 C5
N1.6505 2 SAFETY WASHER M3 E3
N1.6505 ->[P32.0114] 2 SAFETY WASHER M3 C4
N1.7206 ->[P32.1103] 2 PT-SCREW 2.2 X 10 C5+
N1.7207 ->[P32.0114] 4 PT-SCREW 3 X 40 A1+
N1.7208 ->[P32.0114] 4 PT-SCREW 3 X 14 A4+
N2.1107 ->[P32.0114] 1 SECURITY RING E8 C2
N2.1118 2 SECURITY RING E6 A3+
N2.1121 1 SECURITY RING E5 C5
N2.1121 ->[P32.0114] 4 SECURITY RING E5 C5+
N2.1801 ->[P32.0114] 1 TENSIONING RING 4 MM C1
N2.2110 ->[P32.1001] 1 PARALLEL PIN 4 M6 X 10 D3
N2.2145 ->[P32.0103] 3 PARALLEL PIN 4 H6 X 18 C2
N2.2187 ->[P32.0110] 2 PARALLEL PIN 3M6 X 6 E5
N2.2187 ->[P32.1001] 1 PARALLEL PIN 3M6 X 6 D4
N2.2188 ->[P32.1001] 3 PARALLEL PIN 5H6 X 34 D3
N2.2189 ->[P32.0109] 4 PARALLEL PIN 3M6 X 5 E3+
N2.2190 ->[P32.0114] 2 PARALLEL PIN 6H6 X 18 B7
N2.2193 1 PARALLEL PIN 3 m6 X 32 C5
N2.2443 ->[P32.0115] 1 DOWEL PIN 4 X 15 MM B3
N2.2464 ->[P32.0114] 1 DOWEL PIN 2.5 X 16 B1
N2.2601 ->[P32.1001] 1 GROOVED PIN 4 X 10 MM D3
N2.3342 ->[P32.0114] 1 FEATHER KEY 2 X 2 X 10 E2
N2.4902 4 HAMMER HEAD BOLT 1,85 X 4,76 B3+
N2.5132 ->[P32.0114] 1 PRESSURE SPRING 0.5 X 4 X 16 D4
N2.5157 ->[P32.0114] 2 PRESSURE SPRING 0,6 X 4,8 X 20 C3
N2.5178 2 PRESSURE SPRING 0.32X2.82X20.5 D5
N2.5235 ->[P32.0114] 1 PRESSURE SPRING 0.5 X 4.50 X 42.40 /
28.5
C3
N2.5236 ->[P32.0114] 1 PRESSURE SPRING 0.9 X 15 X 59.7 / 7.5 C5
N2.5237 1 PRESSURE SPRING 0.8 X 4.8 X 25 / 18.5 D5
N2.5621 ->[P32.0115] 14 CUP SPRING 15 X 8.2 X 0.7 C3
N2.5822 ->[P32.0114] 1 TORSION SPRING 1,25/11 D1
