Fromm P320 - Page 13

* = Wearing Parts [ ] = Group ->[ ] = in Group
13
N2.5823 1 TORSION SPRING 2,8/59 E4
N3.1134 ->[P32.0114] 1 BALL BEARING C6
N3.1134 ->[P32.1021] 1 BALL BEARING C7
N3.1157 ->[P32.0103] 1 BALL BEARING D2
N3.1158 ->[P32.0107] 1 BALL BEARING B6
N3.1159 ->[P32.0114] 2 BALL BEARING B7
N3.1160 ->[P32.0104] 1 BALL BEARING C1
N3.1172 2 BALL BEARING E4+
N3.1702 ->[P32.0114] 6 BALL 4 MM C4
N3.1703 ->[P32.0114] 1 BALL 5 MM. D4
N3.2105 ->[P32.0103] 3 NEEDLE CAGE C2
N3.2106 3 NEEDLE CAGE D4
N3.2346 ->[P32.0110] 1 NEEDLE CASE D5
N3.2347 ->[P32.0114] 2 NEEDLE BUSH C6
N3.2407 ->[P32.0114] 1 INNER RACEWAY D4
N3.3150 ->[P32.1001] 1 SLIDE-BEARING C2
N3.3172 ->[P32.0109] 3 SLIDE-BEARING E3
N3.3172 ->[P32.1001] 1 SLIDE-BEARING E2
N3.3173 ->[P32.1001] 1 SLIDE-BEARING D4
N3.3174 ->[P32.1101] 1 SLIDE-BEARING C5
N3.4509 ->[P32.1015] 1 NEEDLE FREE WHEELING D1
N4.9108 1 ADHESIVE LABEL 54 X 12 X 0.1 A5
N4.9159 1 LABEL <<CE>> E6
N41.9114 1 TYPE PLATE <<P320>> B4
N41.9127 1 ADHESIVE LABEL D6
N41.9144 ->[N5.4303] 1 ADHESIVE LABEL A6
N5.1129 ->[P32.0107] 1 ELECTRIC MOTOR B7
N5.1129 ->[P32.0108] 1 ELECTRIC MOTOR A2
N5.2322 ->[P32.1103] 2 MICRO SWITCH C5+
N5.2702 1 COVER B3
[N5.4303] 1 BATTERY A6
N5.4304 ->[N5.4303] 1 HOUSING A6
N6.6271 ->[P32.0107] 1 O-RING B7
N6.6271 ->[P32.0108] 1 O-RING A3
P30.1157 1 GUIDE PIN D5
P30.1163 1 GUIDE PIN D5
[P32.0103] ->[P32.0114] 1 IDLER STEP C2
[P32.0104] ->[P32.0114] 1 SPUR WHEEL B1
[P32.0106] ->[P32.0114] 1 ENERGY TRANSMISSION A7
[P32.0107] ->[P32.0114] 1 WELDING MOTOR A7
[P32.0108] ->[P32.0114] 1 TENSIONING MOTOR A3
[P32.0109] 1 TENSIONING BODY E3
[P32.0110] 1 END COVER D6
[P32.0114] 1 BASE MODEL A5
[P32.0115] ->[P32.0114] 1 SPRING PACKAGE B3
[P32.1001] ->[P32.0114] 1 BODY D2
P32.1002 ->[P32.1001] 1 BODY D2
P32.1003 ->[P32.1001] 1 SWIVEL SHAFT E3
P32.1006 ->[P32.0103] 3 IDLER GEAR C2
P32.1007 ->[P32.0103] 1 COVER C1
P32.1008 ->[P32.0114] 1 WHEEL C1
P32.1009 ->[P32.0104] 1 SPUR WHEEL C1
P32.1010 ->[P32.0114] 1 FRONT TOGGLE LINK E2
43.0324.02 P320/12.7/0.65-1.05 P320.0001.02 01/10/98
Item-No. Pcs. Description Dimension Field
