Fromm P320 - Page 14

* = Wearing Parts [ ] = Group ->[ ] = in Group
14
P32.1011 ->[P32.0114] 2 FELT C3+
P32.1012 ->[P32.0114] 1 COUPLER D2
P32.1013 ->[P32.0114] 1 LEVER D1
P32.1014 ->[P32.0114] 1 SHAFT D2
[P32.1015] ->[P32.0114] 1 RATCHET WHEEL C1
P32.1016 ->[P32.1015] 1 SPUR WHEEL D1
P32.1017 ->[P32.0114] 1 STANCHION C1
P32.1018 ->[P32.0114] 1 CARTRIDGE C3
P32.1019 ->[P32.0114] 1 SWITCH ROCKER C2
P32.1020 ->[P32.0114] 1 MOTOR HOUSING C7
[P32.1021] ->[P32.0114] 1 WELDING EXCENTRIC C7
P32.1022 ->[P32.1021] 1 WELDING EXCENTRIC C6
P32.1023 ->[P32.1021] 1 PINION C7
P32.1024 ->[P32.0114] 1 ROCKER C6
P32.1026
*
->[P32.0114] 1 WELDING GRIPPER D4
P32.1027 ->[P32.0114] 1 BALL CAGE C4
P32.1028 ->[P32.0114] 1 BOLT D4
P32.1029 ->[P32.0114] 1 THRUST PIECE C4
P32.1030 ->[P32.0115] 1 SPRING BOLT C3
P32.1031 ->[P32.0115] 1 SPRING SLIDE B3
P32.1032 ->[P32.0114] 1 DRIVING PIN C4
P32.1033 ->[P32.0114] 1 ECCENTRIC SHAFT D5
P32.1034 ->[P32.0114] 1 LEVER D5
P32.1035 ->[P32.0114] 2 DRIVER D4+
P32.1036 ->[P32.0114] 1 COVER C4
P32.1037 ->[P32.0114] 2 SPUR WHEEL B6
P32.1039 ->[P32.0114] 1 SHAFT B2
[P32.1040] ->[P32.0103] 1 PLANET SHAFT C2
P32.1041 ->[P32.0114] 1 CAM B2
[P32.1101] ->[P32.0114] 1 MOTOR HOUSING A5
[P32.1103] ->[P32.0114] 1 CIRCUIT BOARD B6
P32.1105 ->[P32.1103] 1 RETAINER C5
P32.1106 ->[P32.1103] 2 TURNING BUTTON B5
P32.1107 ->[P32.0106] 1 MOTOR SUPPORT A7
[P32.1108] ->[P32.0106] 1 BUSBAR A6
[P32.1111] ->[P32.0106] 1 BUSBAR A6
[P32.1114] ->[P32.0106] 1 BUSBAR A6
P32.1118 ->[P32.0106] 1 CONNECTING PLATE A7
P32.1119 ->[P32.0107] 1 PINION B6
P32.1120 ->[P32.0107] 1 FELT WASHER B7
P32.1121 ->[P32.0107] 2 TORSIONAL STOP B7
P32.1121 ->[P32.0108] 2 TORSIONAL STOP A3
P32.1122 ->[P32.0107] 1 RUBBER BUSHING A7
P32.1122 ->[P32.0108] 1 RUBBER BUSHING B2
P32.1123 ->[P32.0108] 1 PINION A3
P32.1124 ->[P32.0114] 1 INSERT A1
P32.1125 ->[P32.0114] 1 MOTOR COVER A1
P32.1126 ->[P32.0106] 1 PLUG SOCKET B6
P32.1202 1 STEEL INSERT E1
P32.1203
*
1 WELDING STOP GRIPPER E1
P32.1204
*
1 CUTTER D5
P32.1206 1 GUIDE CASE D5
P32.1208 1 CENTERING SLEEVE D6
43.0324.02 P320/12.7/0.65-1.05 P320.0001.02 01/10/98
Item-No. Pcs. Description Dimension Field
