[ ] = Group * = Wearing parts
21
43212401.een.fm
13 SPARE PARTS LIST 43.2124.01
43.2124.01 P322/12.7/0.65-1.05 P322.0001.01 09.09.05
Item-No. in group Pcs. Description Dimension Field
N1.1305 2 SCREW M4 X 7.8 D8
N1.1553 P32.1250 1 HEXAGON SCREW M4 X 8 C12
N1.1904 5 SCREW M5 X 20 C6+
N1.1909 2 FLAT HEAD SCREW M3 X 5 D3
N1.1925 P32.0138 4 SCREW M4 X 20 A7
N1.1929 1 SCREW M5 X 50 D12
N1.1934 P32.0138 6 FLAT HEAD SCREW M4 X 50 A19+
N1.1948 P32.0138 1 SCREW M3 X 35 B16
N1.2112 P32.0118 3 COUNTERSUNK SCREW M4 X 10 B15
N1.2216 1 COUNTERSUNK SCREW M3 X 8 D4
N1.2223 1 COUNTERSUNK SCREW M3 X 6 C5
N1.6331 P32.0138 4 SPACER WASHER 6 X 12 X 0.5 C22+
N1.6503 6 SAFETY WASHER M5 C6+
N1.6504 2 SAFETY WASHER M4 D9
N1.6504 P32.0138 10 SAFETY WASHER M4 A7+
N1.6504 P32.1250 1 SAFETY WASHER M4 C11
N1.6505 2 SAFETY WASHER M3 D3
N1.6505 P32.0138 1 SAFETY WASHER M3 B16
N1.7206 P32.1413 2 PT-SCREW 2.2 X 10 D20+
N1.7207 P32.0138 4 PT-SCREW 3 X 40 A20+
N1.7208 P32.0138 4 PT-SCREW 3 X 14 A21
N2.1118 1 SECURITY RING 6 C24
N2.1121 1 SECURITY RING 5 C11
N2.1121 P32.0138 4 SECURITY RING 5 D9+
N2.1606 1 SPRING RING SW6 A21
N2.1610 P32.0138 1 SPRING RING SB44 B15
N2.1801 P32.0138 1 TENSIONING RING 4 C14
N2.2110 P32.1401 1 PARALLEL PIN 4 m6 X 10 B2
N2.2119 P32.0140 1 PARALLEL PIN 4 m6 X 18 C17
N2.2122 P32.0140 2 PARALLEL PIN 3 h6 X 14 C17
N2.2145 P32.0118 3 PARALLEL PIN 4 h6 X 18 C16
N2.2187 P32.0110 2 PARALLEL PIN 3 m6 X 6 C4
N2.2187 P32.1401 1 PARALLEL PIN 3 m6 X 6 A3
N2.2188 P32.1401 3 PARALLEL PIN 5 h6 X 34 B2+
N2.2189 P32.0136 4 PARALLEL PIN 3 m6 X 5 D3
N2.2190 P32.0138 2 PARALLEL PIN 6 h6 X 18 C22
N2.2193 1 PARALLEL PIN 3 m6 X 32 C10
N2.2443 P32.0139 1 DOWEL PIN 4 X 15 A8
N2.3342 P32.0138 1 FEATHER KEY 2 X 2 X 10 C2
N2.4902 4 HAMMER HEAD BOLT 1.85 X 4.76 C6+
N2.5157 P32.0138 2 PRESSURE SPRING 0.6 X 4.8 X 20/15.5 C9
N2.5178 2 PRESSURE SPRING 0.32 X 2.82 X 20.5/
20.5
D10
N2.5235 P32.0138 1 PRESSURE SPRING 0.5 X 4.50 X 42.4/28.5 C18
N2.5237 1 PRESSURE SPRING 0.8 X 4.8 X 25/18.5 C10
N2.5294 P32.0139 1 PRESSURE SPRING 2.5 X 15 X 46.5/9.5 B9
N2.5295 P32.0138 1 PRESSURE SPRING 1.5 X 21 X 27/5.5 B9
N2.5296 P32.0138 1 PRESSURE SPRING 0.5 X 4 X 24/16.5 C9
N2.5822 P32.0138 1 TORSION SPRING 1.25 X 12/3.75 D15
N2.5823 1 TORSION SPRING 2.8 X 17/4 D4
N3.1134 P32.0138 1 BALL BEARING 7 X 22 X 7 D21
