Fromm P322 - Page 22

[ ] = Group * = Wearing parts
22
43212401.een.fm
N3.1134 P32.1021 1 BALL BEARING 7 X 22 X 7 C22
N3.1157 P32.0118 1 BALL BEARING 30 X 42 X 7 C17
N3.1158 P32.0107 1 BALL BEARING 8 X 16 X 5 B23
N3.1159 P32.0138 2 BALL BEARING 6 X 19 X 6 C22
N3.1160 P32.0119 1 BALL BEARING 40 X 52 X 7 A14
N3.1172 2 BALL BEARING 30 X 42 X 7 B3+
N3.1178 P32.0120 1 BALL BEARING 35 X 44 X 5 A14
N3.1702 P32.0138 6 BALL 4 MM D9
N3.2105 P32.0118 3 NEEDLE CAGE K 4 X 7 X 7 TN B16
N3.2106 3 NEEDLE CAGE K 5 X 8 X 10 TN B3
N3.2346 P32.0110 1 NEEDLE CASE 8 X 12 X 8 C5
N3.2347 P32.0144 2 NEEDLE BUSH 10 X 14 X 12 C21
N3.3172 P32.0136 3 SLIDE-BEARING 8 X 10 X 10 C3
N3.3172 P32.1401 1 SLIDE-BEARING 8 X 10 X 10 C1
N3.3174 P32.0139 2 SLIDE-BEARING 4 X 5.5 X 6 A8+
N3.3174 P32.1419 1 SLIDE-BEARING 4 X 5.5 X 6 C21
N3.4509 P32.1015 1 NEEDLE FREE WHEELING 6 X 10 X 15 C16
N41.9127 1 ADHESIVE LABEL 20 X 10 X 0.1 D12
N41.9160 P32.0138 2 ADHESIVE LABEL 14.4 VOLT A21+
N43.9108 1 TYPE PLATE <<P322>> A7
N4.1803 P32.0142 2 THRUST PIECE B7+
N4.9108 1 ADHESIVE LABEL 54 X 12 X 0.1 A21
N4.9159 1 LABEL <<CE>> C6
N5.1129 P32.0107 1 ELECTRIC MOTOR B24
N5.1129 P32.0108 1 ELECTRIC MOTOR A19
N5.2322 P32.1413 2 MICRO SWITCH D20
N5.2702 1 COVER B20
N5.2702 P32.0138 1 COVER B20
N6.6271 P32.0107 1 O-RING 17 X 3.0 B24
N6.6271 P32.0108 1 O-RING 17 X 3.0 A20
P30.1157 1 GUIDE PIN D10
P30.1163 1 GUIDE PIN D10
[P32.0106] P32.0138 1 ENERGY TRANSMISSION A23
[P32.0107] P32.0138 1 WELDING MOTOR B24
[P32.0108] P32.0138 1 TENSIONING MOTOR A19
[P32.0110] 1 END COVER B6
[P32.0118] P32.0138 1 IDLER STEP B15
[P32.0119] P32.0138 1 SPUR WHEEL A13
[P32.0120] P32.0138 1 WHEEL A14
[P32.0136] 1 TENSIONING BODY D2
[P32.0138] 1 BASE MODEL C1+
[P32.0139] P32.0138 1 SPRING PACKAGE A9
[P32.0140] P32.0138 1 INSERTATION PART C17
[P32.0142] P32.0138 1 LEVER B7
[P32.0144] P32.0138 1 ROCKER D22
P32.1003 P32.1401 1 SWIVEL SHAFT C2
P32.1011 P32.0138 2 FELT C8+
P32.1012 P32.0138 1 COUPLER C7
P32.1014 P32.0138 1 SHAFT C16
[P32.1015] P32.0138 1 RATCHET WHEEL C15
P32.1016 P32.1015 1 SPUR WHEEL C15
P32.1018 P32.0138 1 CARTRIDGE B18
[P32.1021] P32.0138 1 WELDING EXCENTRIC D22
43.2124.01 P322/12.7/0.65-1.05 P322.0001.01 09.09.05
Item-No. in group Pcs. Description Dimension Field
