Fromm P328 - Page 25

1-24
P32.8134/
N3.4509
F3
P32.8159/
N3.3150
F4
P32.2016/
N3.1159
F5
Part Disassembly Assembly
N72.3230
N71.3241
N3.4509*
P32.8134
N72.3229
*Pay attention to the
assembling direction
see assembly information.
N71.3250
P32.8159
N3.3150
N71.3248
*Pay attention to the
direction of the joint
see assembly information
N71.3237
P32.2016
N3.1159
N71.3283
