Fromm P328 - Page 40

[ ] = Group * = Wearing parts
3-5
3.2 Type dependent spare parts P328.0001.01 / P328.0002.01
Type 43.2422.01
Type 43.2423.01
43.2422.01 P328/12/0.65-1.05 P328.0001.01 18.02.16
Item-No. in group Pcs. Description Dimension Field
N44.9160 P32.8105 1 ADHESIVE LABEL D19
[P32.0201] 1 BASE MODEL D6+
[P32.0215] P32.0201 1 CIRCUIT BOARD B21
[P32.8105] P32.0201 1 MOTOR HOUSING B19
P32.8109 * 1 GRIPPER D3
P32.8110 * 1 GRIPPER D3
P32.8111 * 1 GRIPPER D3
[P32.8148] P32.0215 1 CIRCUIT BOARD B20
P32.8150 P32.0201 1 TOUCH CONTACT-SWITCH A21
P32.8162 1 STRAP STOP A1
P32.8172 1 STRAP GUIDE D4
P32.8179 1 GUIDE CASE B11
P32.8181 1 GUIDE PIN D12
P32.8182 1 GUIDE PIN D12
P35.3203 * 1 TENSIONING WHEEL C4
P35.3214 * 1 CUTTER C11
43.2423.01 P328/12.7/0.40-0.64 P328.0001.01 18.02.16
Item-No. in group Pcs. Description Dimension Field
N44.9160 P32.8105 1 ADHESIVE LABEL D19
[P32.0201] 1 BASE MODEL D6+
[P32.0215] P32.0201 1 CIRCUIT BOARD B21
[P32.8105] P32.0201 1 MOTOR HOUSING B19
P32.8112 * 1 GRIPPER D3
P32.8113 * 1 GRIPPER D3
P32.8114 * 1 GRIPPER D3
[P32.8148] P32.0215 1 CIRCUIT BOARD B20
P32.8150 P32.0201 1 TOUCH CONTACT-SWITCH A21
P32.8163 1 STRAP STOP A1
P32.8173 1 STRAP GUIDE D4
P32.8179 1 GUIDE CASE B11
P32.8183 1 GUIDE PIN D12
P32.8191 1 GUIDE PIN D12
P32.8197 1 CUTTER C11
P32.8198 1 INSERTATION PART D9
P35.3202 * 1 TENSIONING WHEEL C4
