Fromm P328 - Page 41

[ ] = Group * = Wearing parts
3-6
Type 43.2424.01
Type 43.2432.01
43.2424.01 P328/12.7/0.65-1.05 P328.0001.01 18.02.16
Item-No. in group Pcs. Description Dimension Field
N44.9160 P32.8105 1 ADHESIVE LABEL D19
[P32.0201] 1 BASE MODEL D6+
[P32.0215] P32.0201 1 CIRCUIT BOARD B21
[P32.8105] P32.0201 1 MOTOR HOUSING B19
P32.8109 * 1 GRIPPER D3
P32.8110 * 1 GRIPPER D3
P32.8111 * 1 GRIPPER D3
[P32.8148] P32.0215 1 CIRCUIT BOARD B20
P32.8150 P32.0201 1 TOUCH CONTACT-SWITCH A21
P32.8163 1 STRAP STOP A1
P32.8173 1 STRAP GUIDE D4
P32.8179 1 GUIDE CASE B11
P32.8183 1 GUIDE PIN D12
P32.8191 1 GUIDE PIN D12
P35.3203 * 1 TENSIONING WHEEL C4
P35.3214 * 1 CUTTER C11
43.2432.01 P328/13/0.65-1.05 P328.0001.01 18.02.16
Item-No. in group Pcs. Description Dimension Field
N44.9160 P32.8105 1 ADHESIVE LABEL D19
[P32.0201] 1 BASE MODEL D6+
[P32.0215] P32.0201 1 CIRCUIT BOARD B21
[P32.8105] P32.0201 1 MOTOR HOUSING B19
P32.8109 * 1 GRIPPER D3
P32.8110 * 1 GRIPPER D3
P32.8111 * 1 GRIPPER D3
[P32.8148] P32.0215 1 CIRCUIT BOARD B20
P32.8150 P32.0201 1 TOUCH CONTACT-SWITCH A21
P32.8164 1 STRAP STOP A1
P32.8174 1 STRAP GUIDE D4
P32.8179 1 GUIDE CASE B11
P32.8185 1 GUIDE PIN D12
P32.8193 1 GUIDE PIN D12
P35.3203 * 1 TENSIONING WHEEL C4
P35.3214 * 1 CUTTER C11
