[ ] = Group
25
43026601.een.fm
P32.1411 P33.0118 1 LEVER C17
P32.1412 P32.0140 1 INSERTATION PART C16
[P32.1414] P33.0101 1 LEVER C24
P32.1422 P32.1414 1 LEVER D24
P32.2009 P33.1110 2 TURNING BUTTON C20
P32.2012 P33.0118 1 GUIDE C18
P32.2024 P33.0101 1 PRESSURE BUTTON A21
P32.2030 P33.0101 1 DISK B21
P32.2036 P32.0156 1 GEAR WHEEL C15
P32.2063 P33.0104 1 DISK B23
P32.2064 P33.0104 1 COOLING PLATE B23
P32.2067 P33.0118 2 CENTERING SLEEVE B7
[P33.0101] P33.0118 1 DRIVE C19
[P33.0102] P33.0101 1 GEAR WHEEL A23
[P33.0103] P33.0101 1 CONICAL GEAR WHEEL B22
[P33.0104] P33.0101 1 MOTOR B22
[P33.0105] P33.0118 1 BODY A1
[P33.0106] 1 TENSIONING BODY B2
[P33.0107] 1 END COVER C6
[P33.0110] P33.0118 1 SPRING PACKAGE A9
[P33.0111] P33.0118 1 WHEEL A14
[P33.0112] P33.0118 1 GEAR WHEEL A14
[P33.0113] P33.0118 1 IDLER STEP B16
[P33.0114] P33.0118 1 ROCKER A16
[P33.0115] P33.0118 1 WELDING EXCENTRIC A17
[P33.0118] 1 BASE MODEL C19
[P33.0119] 1 COUPLER C11
P33.1101 P33.0101 1 MOTOR HOUSING B24
P33.1102 P33.0101 1 COVER A22
P33.1103 P33.0101 1 INSERTATION PART A22
P33.1104 P33.0102 1 GEAR WHEEL A24
[P33.1105]
*
P33.0104 1 ELECTRIC MOTOR B23
P33.1108 P33.0103 1 CONICAL GEAR WHEEL B21
[P33.1110] P33.0101 1 CIRCUIT BOARD C21
[P33.1111] P33.0101 1 HANDLE LEVER B23
P33.1112 P33.0101 1 HANDLE SHAFT C24
[P33.1114] P33.0101 1 MOTOR HOUSING B20
[P33.1116] P33.0101 1 PINION C21
P33.1201 P33.0105 1 BODY D17
P33.1203 P33.0118 1 GEAR WHEEL A18
P33.1204 P33.0112 1 GEAR WHEEL A13
P33.1205 P33.0111 1 WHEEL A14
P33.1206 P33.0113 3 PINION B15
P33.1207 P33.0113 1 PLANET SHAFT C16
P33.1208 3 PINION B4
P33.1209 P33.0113 1 COVER B15
P33.1210 P33.0118 1 COUPLER C9
P33.1211 P33.0118 1 COUPLER B10
P33.1212 P33.0118 1 FRONT TOGGLE LINK C1
P33.1213 P33.0118 1 LEVER D15
P33.1214 P33.0114 1 ROCKER B17
P33.1215
*
1 TENSIONING WHEEL C5
P33.1216 P33.0118 1 STEEL INSERT D7
43.0266.01 P330/25.0/1.20-1.35/6.0 P330.0001.01 17.02.09
Item-No. in group Pcs. Description Dimension Field
* = Wearing parts
