Fromm P330 - Page 26

[ ] = Group * = Wearing parts
26
43026601.een.fm
P33.1217
*
P33.0118 1 WELDING STOP GRIPPER D7
P33.1218
*
P33.0118 1 WELDING GRIPPER D10
P33.1219 P33.0118 1 BOLT D10
P33.1220 P33.0118 2 DRIVER D10+
P33.1221 P33.0118 1 DRIVING PIN D10
P33.1224 P33.0110 1 SPRING BOLT B9
P33.1225 P33.0110 1 SPRING SLIDE A9
P33.1226 P33.0118 1 FIXING PLATE A9
P33.1228 P33.0118 1 COVER B7
P33.1229 P33.0118 1 HOOK C18
P33.1230
*
1 CUTTER C10
P33.1233 1 GUIDE CASE D11
P33.1236 1 GUIDE PIN D11
P33.1237 1 GUIDE PIN D11
P33.1238 1 SEESAW LEVER C10
P33.1239 1 SEESAW LEVER C11
P33.1240 P33.0119 1 THRUST PIECE C11
P33.1241 1 CENTERING SLEEVE C11
P33.1242 1 COVER D12
P33.1243 P33.0105 1 SWIVEL SHAFT B2
P33.1245 P33.0106 1 TENSIONING BODY D2
P33.1246
*
1 GRIPPER C3
P33.1247
*
1 GRIPPER C3
P33.1248
*
1 GRIPPER C3
P33.1249 1 HOLDER C3
P33.1250 1 HOLDER B2
P33.1252 1 STRAP STOP D3
P33.1254 1 STRAP GUIDE D5
P33.1255 P33.0107 1 END COVER C6
[P33.1260] P33.0118 1 LEVER B7
43.0266.01 P330/25.0/1.20-1.35/6.0 P330.0001.01 17.02.09
Item-No. in group Pcs. Description Dimension Field
