Parameter Range of values Standard
value
Description
"Threshold Stat-
ic"
0 200
[% UacNominal]
125 % Voltage threshold (in % of
nominal voltage) that must
be exceeded or fallen be-
low to activate VFRT re-
gion 1 and its associated
current inrush mode.
-
> 100 % ... Region 1 is
used as the HVRT re-
gion.
-
< 100 % ... Region 1 is
used as the LVRT re-
gion.
Setting condition:
Threshold R1 > Threshold
R2 > Threshold R3
"k-factor Posit-
ive Sequence"
0 10 2.0 Multiplication factor (k-
factor) for the positive-se-
quence system reactive
current in region 1.
Only applied with current
inrush mode "Active Sym-
metric Current" and "Act-
ive Asymmetric Current".
"k-factor Negat-
ive Sequence"
0 10 2.0 Multiplication factor (k-
factor) for the negative-
sequence system reactive
current in region 1.
Only applied with current
inrush mode "Active
Asymmetric Current". If
an asymmetrical feed is
required, this is usually set
to the same value as "k-
factor Positive Sequence".
If symmetrical supply is
required, this is set to 0.
32
