Fronius GEN24 - Page 39

Parameter Range of val-
ues
Description Availability
"Activation
Threshold Over-
voltage"
208 ‑ 311 [V] Mains voltage limit value
above which the power re-
duction takes place.
"Gradient Over-
voltage"
0.01 ‑ 100 [%/
V]
Gradient by which the ef-
fective power is reduced.
Example - conversion from
static to gradient:
Static s = 4 % → Gradient k
= 1/(0.04*230 V) =
10.9 %/V
"Calculation
Mode"
P
max
=
P
m
-P
m
(k*dV)
P
max
=
P
n
-P
n
(k*dV)
P
max
=
P
m
-P
n
(k*dV)
Indicates the reference
power for calculating the
power limit in the event of
overvoltage or under-
voltage.
Reference power:
-
P
m
→ Momentary
power when the
mains voltage limit
value is exceeded.
-
P
n
→ Nominal power
of the device.
"Active Grid
Support"
Off Deactivates extended act-
ive mains support for
devices with battery.
Has no in-
fluence on
the follow-
ing setups:
-
AUS
Region
A 2020
-
AUS
Region
B 2020
-
AUS
Region
C 2020
-
NZS
2020
On Activates extended active
mains support for devices
with battery.
"Activation
Threshold Un-
dervoltage"
0 ‑ 311 [V] Mains voltage limit value
above which the power in-
crease takes place.
"Gradient Un-
dervoltage"
0 ‑ 100 [%/V] Gradient by which the ef-
fective power increases.
Example - conversion from
static to gradient:
Static s = 4 % → Gradient k
= 1/(0.04*230 V) =
10.9 %/V
39
EN
